Weight capacity – Metro Worktable, HD, Stainless Steel User Manual
Page 4
![background image](/files/798343/content/doc004.png)
7. Attach worksurface
8. Attach optional backsplash
(phenolic worksurface)
9. Install optional wire shelf
onto 3-sided frame
Place the worksurface upside down on a non-scratching surface on the floor. Identify the rear of
the phenolic worksurface by the partially drilled holes along the back edge (for attaching the
optional backsplash).
Clean the bottom of the worksurface with household cleaner and remove the backing from the
mounting tape on the top frame.
Turn the table frame upside down and carefully lower the frame onto the worksurface. As shown
below, align the guidelines on the bottom of the worksurface with the inside center edges of the
frame (see right). Press the frame down to assure good adhesion.
If the table is mobile, attach the casters (casters were ordered separately).
Remove the protective plastic from the top of the worksurface
and the front of the backsplash. Use a drill to drive the drill-point
screws up through the partially drilled holes until they break the
top surface.
Place the backsplash into position, aligning the holes. Drive the
screws up into the holes in the backsplash.
You may optionally apply silicone sealant to the joint between
the backsplash and the worksurface.
Position the wire shelf on the 3-sided frame as shown.
Attach a clip near the center of each end of the shelf.
Hook the clips over the wire shelf, then wrap the lower
part around the bottom of the 3-sided frame to secure
the shelf
Weight Capacity
150 lbs. (68kg)
4
North Washington Street, Wilkes-Barre, PA USA 18705
For Product Information, Call
Pour de plus amples renseignements sur les produits,
appeler au 570-825-2741
Para obtener información sobre el producto llame al: 570-825-2741
1-800-433-2232
Information and specifications are subject to change
without notice. Please confirm at time of order
Les données et caractéristiques techniques sont
susceptibles d'être modifiées sans préavis. Veuillez
confirmer au moment de la commande.
Las informaciones y especificaciones están sujetas a
cambios sin previo aviso. Por favor, confirme a la vez
que realiza el pedido.
INSTR-SSLT 5/2006
R
InterMetro Industries Corporation
Visit our Web Site / Visitez notre site Web / Visite nuestro sitio en la Web: www.metro.com
guidelines
Clip (x2)
