Deck Assembly
003-2132a
No.
Qty
.
P/N
Description
1
1
438-0072
Paint Deck CV
-260
2
1
438-0070
Paint Mid-Plate
Assy
.
3
4
329-0002
Scr Hex 1/4-20 x 5/8
4
1
261-0510
Spool Insulator
5
1
003-2078
Assy Slave Motor 1
15V
6
4
333-0009
W
asher Spring Loc 01/4 ID
7
1
438-0044
Paint Panel
Access
T
riac CV
-260
8
1
329-0208
Scr Hex 3/8 -16 x 1.0
9
0.50ft
261-0505
T
rim Protection Edge
10
1
003-0784
Assy Pawl Ratchet
1
1
1
003-2146
Assy Spindle CB
12
6
351-0086
Insert Thread
#6-32
13
4
331-0002
W
asher Flat #6
14
1
003-0593
Assy Relay
15
12
333-0043
W
asher Star-In #6
16
12
336-0005
Scr Ph Phl St #6-32 x 3/8
17
2
41
1-0186
Strap Cable
18
2
305-0042
Pop Rivet 1/8
Al.
19
1
003-2096
Assy Sol Brk 1
15V
20
3
336-0037
Scr Ph Phl St #6 x 1/4
T/B
21
1
419-0080
Spring Extension
22
6
342-0410
Spacer #6-32
23
1
003-1628
Assy Pcb main Cb 1
15V
24
1
405-0072
Decal Elec Connection
25
1
405-0929
Decal Main Pcb Connections
26
2
351-0752
Bushing Snap 01.50
27
5
327-01
15
Scr Hex Sht Mtl #14 x 1/2
28
1
003-2063
Assy Power Block CB
29
1
261-0109
Insulator Power Block
30
1
435-1502
Bracket Power Block
31
2
332-0009
W
asher Shoulder 01/4
32
2
331-0049
W
asher Flat 01/4
33
2
329-0003
Scr Hex 1/4-20 x 3/4
34
1
405-0930
Decal Hose Connections
35
4
329-0405
Scr Hexwshrhd Hi-Perf 8-32 x 3/8
36
1
405-0886
Decal W
arning
T13297
37
1
405-0887
Decal W
arning
T13470
