Operation Section

16

3. CONSTRUCTION

3.1 Internal Structure

I003089

Evaporator

Room Thermistor
(RTS)

Freeze Protection
Thermistor (CTS)

Power Cord

Controller

Condenser

Condenser Fan
and Motor

Evaporator Fan Motor

Evaporator Air Outlet

Condenser Air Outlet

Control Box
