Nevion SFP-3G-EO-OE-C1xxx-L - Manual (Page 5)

23036 SFP-3G-EO-OE-C1xxx-L Rev. A
nevion.com | 5
2
Specifications
Power <1.5W
Size SFP compliant, INF-8074i
Control Multicon Gyda control and status
Operating temperature 0 to +70 °C
Supported standards
SD, 270Mbps SMPTE259M
HD, 1485Mbps SMPTE292-2008
3G, 2999Mbps SMPTE424M
DVB-ASI EN50083-9.
Fiber Transmission SMPTE297-2006
Optical SDI input
Connector LC/UPC single mode
Wavelength 1260nm to 1620nm
Sensitivity -27dBm
Overload -6dBm
Optical SDI output
Connector LC/UPC single mode
Center wavelength 1270nm to 1610nm in 20nm step
Center offset +/- 7.5nm
Extinction ratio min 7dB
Power 0 to 4dBm, typ 2dBm
