SIERRA PRO XL FAMILY OVERVIEW
9
Model Suffix Designations
Model Suffix Designations
V Analog video (450MHz bandwidth)
88, 84, 128, 124 Matrix size
# Number of video and sync channels (analog, YC, RGB, RGB+HV etc.)
S Stereo audio
R Redundant Power Supplies
Sierra PRO System Components
This User's Manual provides installation and operation information for the Series 12 and Series 8
Routing Switchers. Front and Rear panel illustrations are provided in the following subsections for
each switcher model. Take time to familiarize yourself with the location of your switcher model
features
Component
Sierra PRO Family 8 & 12 Switchers
 1208V5S, 1208V5, 1208V4S,
1208V4, 1208V3S, 1208V3 & lower
 1204V5S, 1204V5, 1204V4S,
1204V4, 1204V3S, 1204V3 & lower
 88V5S, 88V5, 88V4S, 88V4,
88V3S, 88V3 & lower
 84V5S, 84V5, 84V4S, 84V4,
84V3S, 84V3 & lower
Video Frame  Video and Audio contained in one
frame
 Power Supply(ies)
 Video Motherboard Board
 Audio Motherboard Board
 Local Control Panel
 Video and Audio contained
in one frame
 Power Supply(ies)
 Video Motherboard Board
 Audio Motherboard Board
 Local Control Panel
Accessory Kit  User’s Manual
 5-pin Audio Connectors
 Fuses
 Power Cord
 Software Disk
 User’s Manual
 5-pin Audio Connectors
 Fuses
 Power Cord
 Software Disk
