Thank you for choosing Silva Trail Runner II USB headlamp. This
ultra-compact high power headlamp is designed for sportsmen who
value performance, weight and easy charging.
The Trail Runner II™ USB headlamp is equipped with Silva Intelligent
Light ® which is a light distribution technology that combines a wide
angle flood light with a long reach spot light. This unique light image
gives the user peripheral and long distance vision at the same time.
For a runner, cross country skier, mountain biker or night orienteer
this translates into less head movement, increased control, better
balance and more speed.
PRODUCT OVERVIEW
The Trail Runner II USB headlamp consists of the following parts:
• Headlamp unit
• Head band
• 1x Li-Po battery with battery soft case
• Quick guide
BEFORE USE
BATTERY CHARGING
1. Connect the battery to a USB charger or the USB connection on
the computer
2. Connect the charger to the wall outlet or turn the computer on
3. On the battery there is an LED showing the battery status during
charging:
- green light = battery is fully charged
- red light = battery is charging
- blinking red light = battery is not working properly
Battery charging time is approximately 4 hours.
Note! When the battery is fully charged the battery automatically
switches to maintenance charge.
ADJUST THE HEADBAND
The elastic headband with anti-slip rubber on the inside is designed
to give a comfortable fit at speed activities such as running, XC
skiing etc. Adjust the headband by moving the sliding buckle to fit it
onto your head.
CONNECT THE BATTERY TO THE HEADLAMP
Fasten the battery on the headband and connect the battery cable to
the headlamp cable.
DURING USE
SWITCH ON YOUR HEADLAMP 2
On the side of the headlamp body there is a push button which
controls all light modes.
Each press on the button gives you the following light:
1. Turns the headlamp ON in max mode.
2. Switches to Min mode
3. Starts over from 1
To turn OFF the headlamp; press and hold the button for 1 second. 3
The flash function, which is used to attract attention, is started from
OFF mode by pressing and holding the button for 1 second. To turn
OFF; press and hold the button for 1 second.
4
BATTERY STATUS INDICATION 3
When the headlamp is turned off a small LED is turned on inside the
front of the headlamp to indicate the status of the batteries. This
indication will be on for 5 seconds.
Green light – Battery in good condition
Red – Battery in poor condition
Note! As the Trail Runner II USB is a high power headlamp the torch
will become warm during use. The torch is constructed with protec-
tion case to prevent overheating of the electronics and therefore will
not affect the performance or durability in any way.
AFTER USE
MAINTENANCE
To make sure you get maximum performance from your Trail Run-
ner II USB headlamp, clean it regularly with a damp cloth.
Headset cleaning – rinse in warm water.
ABOUT LI-PO BATTERIES
The battery should be stored in a dry environment within the
temperature range of -20°C and +60°C.
If you would like to store your battery for a longer period (more than
30 days) the battery should not be fully charged. This may cause loss
of its characteristics.
Li-Po batteries have a discharge rate of approx. 20% over a 30 day
period. You can always charge a half full battery without damaging
its characteristics.
Do not expose the battery for extreme temperatures which may
cause fire or explosion.
Do not disassemble or mistreat the battery, risk for chemical burn.
Keep away from children.
Do not dispose of batteries in fire. This may cause an explosion. Do
not submerge the batteries in water.
Do not short circuit the contacts.
Replace only with Silva Trail Runner II USB batteries.
Note! Always make sure to disconnect the battery when the head-
lamp is not used.
TECHNICAL SPECIFICATIONS
Weight: headlamp (including head bracket): 130g
Battery type: Li-Po 3,7V, 1800mA
Light distance (Max/Min): 50m / 25m
Lumen: 150
Burn time: Max/Min/Flash: 7 hours/ 14 hours/ 14 hours
Water resistance: IPX6
Operative temperature range: -20 - +60º
PROTECT THE ENVIRONMENT.
Headlamp and batteries should be recycled and must not be thrown
in the regular trash. Dispose these items in accordance with appli-
cable local regulations.
WARRANTY
Silva warrants that, for a period of two (2) years, your Silva Product
will be substantially free of defects in materials and workmanship
under normal use. Silva’s liability under this warranty is limited to
repairing or replacing the product. This limited warranty extends
only to the original purchaser.
If the Product proves defective during the Warranty Period please
contact the original place of purchase. Make sure to have your proof
of purchase on hand when returning the product. Returns cannot
be processed without the original proof of purchase. This warranty
does not apply if the Product has been altered, not been installed,
operated, repaired, or maintained in accordance with instructions
supplied by Silva, or has been subjected to abnormal physical or
electrical stress, misuse, negligence or accident. Neither does the
warranty cover normal wear and tear. Silva is not responsible for any
consequences, direct or indirect, or damage resultant from use of
this product. In no event will Silva’s liability exceed the amount paid
by you for the product. Some jurisdictions do not allow the exclusion
or limitation of incidental or consequential damages, so the above
limitation or exclusion may not apply to you. This Warranty is valid
and may be processed only in the country of purchase.
For more information please visit www.silva.se
