Smithco Super Star 42-00x (sn 4841 – 4984/12712 – 12799) Parts & Service Manual - Manual (Page 95)

93
Accessories
42-700 WIRING DIAGRAM PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 8975 30 Amp Circuit Breaker (on machine)
2 12-003 Toggle Switch 1
15-472 Switch Boot 1
* 42-701 Wire Harness (included all wires with *) 1
42-700 LEAF & DEBRIS BLOWER PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 42-703 Short Guard Spacer 1
2 HB-38-16-125 Bolt, 3 /
8
-16 x 1¼ 7
HNFL-38-16 Flange Whiz-Lock Nut, 3 /
8
-16 7
3 78-222 Mounted Bearing (1" Bore) 1
4 42-709 Damper 2
8803-12 Black Trim, 12" 2
25-286 Decal, Pinch Point (one per Damper) 2
5 HB-38-16-100 Bolt, 3 /
8
-16 x 1 8
HNTL-38-16 Lock Nut, 3 /
8
-16 8
6 42-706 Housing 1
7 42-705 Left Hand Blower Stand 1
8 42-707 Blower Mount Bracket 2
9 HNFL-12-13 Flange Whiz-Lock Nut, ½ - 13 4
10 13-493 Muffler Extension 1
11 13-498 Clamp 1
12 HCP-34-250 Clevis Pin, ¾ x 2½ 1
13 HSTP-14-20-075 Phillips Head Machine Screw, ¼ - 20 x ¾ 4
14 42-714 Cylinder Stop 1
15 HCP-12-300 Clevis Pin, ½ x 3 1
16 HHP-18 Bridge Pin, 1 /
8
2
17 42-704 Right Hand Blower Stand 1
18 42-718 Belt Guard 1
78-274 Cage Nuts 4
16-088 Decal, Moving Parts / Hot 1
19 HKSQ-14-100 Machine Key, ¼ x ¼ x 1 3
20 42-719 Coupling 1
21 HB-12-13-100 Bolt, 1 /
4
-20 x 1 4
22 78-347 Spring Pin 2
23 78-301 Fan 1
24 HB-516-18-225 Bolt, 5 /
16
-18 x 2¼ 8
HNFL-516-18 Flange Whiz-Lock Nut, 5 /
16
-18 8
25 42-711 Vent Plate 1
26 HNFL-516-18 Flange Whiz-Lock Nut, 5 /
16
-18 8
27 42-702 Guard Spacer 8
28 42-710 Guard 1
76-305 Decal, Rotating Parts 1
29 HB-38-16-250 Bolt, 3 /
8
- 16 x 2½ 1
HNFL-38-16 Flange Whiz-Lock Nut, 3 /
8
-16 1
30 42-190 Park Brake Bracket 1
31 HSDPS-14-075 Pan Head Drill Screw, 1 /
4
x
3 /
4
6
32 42-720 Seal Plate 2
33 42-721 Damper Seal 2
