Smithco Super Star 42-000-F (sn 6390 -Current) Parts & Service Manual - Manual (Page 17)

15
Diagrams
HYDRAULIC PARTS LIST
REF # PART # DESCRIPTION QUANTITY
1 76-238 Front Wheel Motor 1
2 43-070 Hydraulic Hose 1
3 10-554 Hydraulic Cylinder(belly lift) 1
18-154 Rod End 1
HNJ-58-18 Jam Nut 5 /
8
- 18 1
4 42-047 Hydraulic Hose 2
5 13-729 2 - Bank Hydraulic Valve 1
78-454 Valve Handle 2
6 42-048 Hydraulic Hose 2
7 43-150 Hydraulic Cylinder(rear rake) 1
43-138 Lift Linkage 1
8 42-044 Hydraulic Hose 1
9 18-170 Tee 2
10 43-094 Hydraulic Tube 2
11 13-615 Rear Wheel Motor 2
12 42-259 Hydraulic Hose 10 3 /
4
" 1
13 42-797 Variable Pump 1
14 8832-45 Suction Hose 1
18-222 Hose Clamp 2
15 42-787 Hydraulic Hose 1
16 23-006 Oil Filter 1
23-031 Replacement Filter Only
17 8832-24 Suction Hose 1
18-222 Hose Clamp 2
18 42-005 Oil Tank 1
13-747 Filler Breather 1
19 42-256 Hydraulic Hose 1
20 34-105 Oil Cooler 1
21 42-045 Hydraulic Hose 1
22 43-095 Hydraulic Tube 2
23 43-071 Hydraulic Hose 1
HYDRAULIC PRESSURES
Pump Displacement .913 in 3 /rev Charge Pump Displacement .33 in 3 /rev
Pump Input Speed (up to) 3600 rpm Max. Inlet Vacuum 5 in. Hg
Max. Operating Pressure 3500 psi, 2500 peak psi Max. Case Pressure 25 psi
Implement Setting 700-1000 psi Relief Valve Pressure (set at) 2500 psi
13-729 Hydraulic Valve (2 bank) 900 psi
