FRONT FORK PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 HW-516 Washer 5 /
16 (as Req'd) 14
2 HB-38-16-200 Bolt 3 /
8
- 16 x 2 2
HNTL-38-16 Locknut 3 /
8
- 16 2
3 HB-38-16-250 Bolt 3 /
8
- 16 x 2 1 /
2
2
HNTL-38-16 Locknut 3 /
8
- 16 2
4 75-715 Shock Absorber 2
75-715-01 Bushing with Insert 2 per shock
5 HN-38-16 Nut 3 /
8
- 16 2
6 HB-38-16-100 Bolt 3 /
8
- 16 x 1 2
7 20-142 Grease Seal 1 1 /
4
2
8 HNA-114-12 Axle Nut 1 1 /
4
- 12 1
9 HP-18-150 Cotter Pin 1 /
8
x 1 1 /
2
2
10 20-143 Bearing Cup and Cone 1 1 /
4
ID 2
11 20-141 Spacer 1 5 /
8
OD x 1 1 /
4
ID x 7 /
16
1
12 HNCL-38-16 Lock Nut 3 /
8
- 16 2
13 76-155 Front Fork 1
14 27-022-02 Bolt Stud 1 /
2
- 20 x 1 1 /
2
5
HNL-12-20 Lug Nut 1 /
2
- 20 5
15 11-039 Grease Seal 1 1 /
8
ID 2
16 11-040 Spacer 1 1 /
8
OD x 3 /
4
ID x 17 /
32
2
17 HB-58-18-350 Bolt 5 /
8
- 18 x 3 1 /
2
2
18 HNJ-34-16 Jam Nut 3 /
4
- 16 2
19 HNA-34-16 Axle Nut 3 /
4
- 16 2
20 60-511 Axle Lock 2
21 60-510 U-Bracket 1
22 60-407 Front Axle 1
23 11-038 Bearing Cup and Cone 3 /
4
ID 2
24 11-010 Wheel Hub 1
25 60-130 Wheel and Tire 1
60-130-01 Tire 18 x 9.5 - 8 6 Ply 1
60-130-02 Wheel 1
8839 Windshield Washer Fluid 28 pints
26 60-128 Rubber Bushing 4
27 60-406 Spacer 1 OD x 5 /
8
ID x 2 2
28 HW-58 Washer 5 /
8
2
29 HNTL-58-18 Lock Nut 5 /
8
- 18 2
30 75-676 Spacer Seal 1
31 HP-18-200 Cotter Pin 1 /
8
x 2 1
