Introduction
SPECIFICATIONS FOR SWEEP STAR 48 HIGH LIFT & GROUND DUMP
WEIGHTS AND DIMENSIONS HIGH LIFT GROUND DUMP
Length 121" (307 cm) 108" (274 cm)
Width 60" (153 cm) 60" (153 cm)
Height with Hopper Down 63" (160 cm) 63" (160 cm)
Height with Hopper Up 126" (320 cm) na
Wheel Base 70" (179 cm) 70" (179 cm)
Weight 1800 lbs(818 kg) 1700 lbs(772 kg)
SOUND LEVEL (DBA)
At ear level 90 dba
At 3 ft (0.914 m) 91 dba
At 30 ft (9.14 m) 76 dba
ENGINE
Make Kohler
Model# TH18S
Type / Spec# PA-54517
Horsepower 18 Hp (13.4 kw)
Fuel Unleaded 87 Octane
Gasoline Minimum
Cooling System Air Cooled
Lubrication System Full Pressure
Alternator 15 Amp
WHEELS & TIRE
Front: One 18 x 9.50 x 8 Multi-rib
Rear: Two 23 x 10.50 x 12 NHS (20 psi max)
Castor: 9 x 3.50 - 4
BRAKES
Dynamic Through Hydrostat
PARK BRAKE
Hand Operated Lever, Discs on Rear Axle
SPEED
Forward Speed 0 to10 mph (0-16kph)
Reverse Speed 0 to 4 mph (0-6 kph)
BATTERY
12 Volt Automotive IBS type 45-50
Cold Cranking Amps 48 minimum
Ground Terminal Polarity Negative (-)
Maximum Length 9" (23cm)
Maximum Width 5.38" (14cm)
Maximum Height 9" (23cm)
FLUID CAPACITY
Crankcase Oil See Engine Manual
Fuel 5 gallon (19 liters)
Hydraulic Fluid 5 gallon (19 liters)
Grade of Hydraulic Fluid SAE 10W-40 API Service SG Motor Oil
OPTIONAL EQUIPMENT
48-084 48" Brush Reel Kit (includes pillow blocks and pulley drive)
48-085 48" Finger Reel Kit (includes pillow blocks and pulley drive)
48-120 Dust and Filtration pack - High lift
48-121 Dust and Filtration Pack - Ground Dump
