Issue 4, December 2000

Model 58/59 User Guide

Page 58

Studio Technologies, Inc.

for Surround

Appendix B

Model 58 Single-Channel
Mode

DIP switch 5 on the Model 58’s front panel
allows the operating mode to be set.
Installations that utilize a Model 59 Control
Console will use the two-channel mode,
configured by setting DIP switch 5 to the
off (down) position. In this mode, a Model
58 supports two output channels and four
2-channel input pairs. Special applications
can use the Model 58’s single-channel
operating mode, configured by setting DIP
switch 5 to the on (up) position. Figures
12, 13, and 14 provide detailed connection
information for the inputs, outputs, and
inserts when a Model 58 is operating in
the single-channel mode.

The concept of the single-channel mode
is simple: The signal flow is organized so
that any of the eight main inputs can be
routed to one monitor and meter output.
(This is in contrast to the two-channel
mode where the eight main inputs are
organized as four pairs.) In the single-
channel mode, a maximum of four of the
8 inputs can be simultaneously routed to
one output channel. Specifically, monitor
output 1 (A and B), meter output 1, insert
1/channel 1, insert 2/channel 1 are active
in the single-channel mode. Monitor output
2 (A and B), meter output 2, insert 1/
channel 2, and insert 2/channel 2 are
disabled.

It is expected that a number of applica-
tions for the single-channel mode will
arise. A special version of the Model 59
Control Console can be created at the
factory to allow up to eight 8-channel

Figure 12. Single-Channel Mode Connections
for Main Inputs

sources to be connected to eight Model 58
units. It is also anticipated that custom
installations will be created that generate
MIDI system-exclusive messages to
“drive” Model 58 units. Contact the factory
for additional information.

Signal

Signal

Connection

High (+)

Low (–)

Shield

MAIN IN 1

24

12

25

MAIN IN 2

10

23

11

MAIN IN 3

21

9

22

MAIN IN 4

7

20

8

MAIN IN 5

18

6

19

MAIN IN 6

4

17

5

MAIN IN 7

15

3

16

MAIN IN 8

1

14

2

Notes: 1) Connector type on Model 58 is 25-pin

D-subminiature female. Installer must
provide plug (male). Connector uses 4-40
threaded inserts for locking with mating plug.

2) Wiring scheme follows Tascam DA-88
convention. Standard DA-88-type wiring
harnesses are directly compatible, with the
exception of 4-40 screw threads being
required.
