1.0 Introduction
Thank you for selecting a SunPumps SCS series solar pump system. The SCS series
pump and PCA series pump controller are the key components to high quality solar
powered pumping systems. Their stand-alone, pollution free and low noise operation
makes them an ideal solution for remote homes, wildlife and stock watering problems
without violating the environment.
SunPumps SCS series pumps are multi-stage centrifugal, brushless, sensorless three
phase DC powered, submersibles constructed of high quality stainless steel. These pumps
were designed specifically for water delivery in remote locations.
The PCA-series controllers are micro-processor-based, solid-state DC power converters
designed as the interface between a solar module array and a brushless, sensorless three
phase DC pump motor. The purpose of the controller is to maximize the total daily water
output while providing protection for the pump as well as providing an interface with
other related pumping system equipment.
Although these SCS series pump systems are easy to install, please read this manual
to become familiar with the controller features, functions, connection points and
various configurations. For future reference, keep this manual and other relevant
product information in a safe place.
PRECAUTIONS
 Safety First – Always understand what you are doing when working with any
form of electricity. Guessing at something is not worth the potential of
product damage and/or severe personal injury.
 Shut down all power when working on the system.
 Do not attempt to feed live wires into the PC-series controller or product
damage and/or personal injury may result.
 Do not exceed the voltage and power rating of the controller.
 Do not splash water on the controller when the cover is open.
 Mount the controller in a shaded, well vented, vertical position.
 Installation of this system should be done by a licensed Solar Pump
Contractor.
2.0 Product Overview
SunPumps PCA series controllers were primarily designed for the 24V, 48V, 60V, and
120V SCS-series, brushless, sensorless three phase DC submersible pump. When
properly installed and configured, the unique features incorporated into this stand-alone
system will automatically control and protect your pump system permitting many years
of dependable, trouble free service.
SunPumps has produced multiple versions of this
controller. The differences between the versions are certain set points and electrical characteristics which
are detailed in the table on the next page.
