Model 212B-EM Elbow Mandrels
92-0262 : Rev. 970321
Contact
Pin P/N
Pin Chart
32-0318 1.58" (40.0 mm)
32-0319 2.03" (51.5 mm)
32-0320 2.48" (63.0 mm)
32-0321 2.91" (73.9 mm)
32-0322 3.36" (85.4mm)
32-0323
3.82"
(96.9 mm)
32-0324
4.27"
(108.4 mm)
CENTERING PINS
Pin Length Measuring Guide
