20 6621-2214
S2 DIP-switch
ON
1 2 3 4 5 6 7 8
Ethernet auto-negotiation disabled
ON
1 2 3 4 5 6 7 8
Ethernet auto-negotiation enabled
ON
1 2 3 4 5 6 7 8
Ethernet speed 10 Mbit/s
(if auto-neg. disabled)
ON
1 2 3 4 5 6 7 8
Ethernet speed 100 Mbit/s
(if auto-neg. disabled)
ON
1 2 3 4 5 6 7 8
Ethernet half duplex
(if auto-neg. disabled)
ON
1 2 3 4 5 6 7 8
Ethernet full duplex
(if auto-neg. disabled)
ON
1 2 3 4 5 6 7 8
DSL-speed 192 kbit/s*
DSL-speed 6200 kbit/s**
ON
1 2 3 4 5 6 7 8
DSL-speed 384 kbit/s*
DSL-speed 6712 kbit/s**
ON
1 2 3 4 5 6 7 8
DSL-speed 512 kbit/s*
DSL-speed 7224 kbit/s**
ON
1 2 3 4 5 6 7 8
DSL-speed 768 kbit/s*
DSL-speed 7736 kbit/s**
ON
1 2 3 4 5 6 7 8
DSL-speed 1024 kbit/s*
DSL-speed 8248 kbit/s**
ON
1 2 3 4 5 6 7 8
DSL-speed 1280 kbit/s*
DSL-speed 8760 kbit/s**
Factory settings
ON
1 2 3 4 5 6 7 8
S1
ON
1 2 3 4 5 6 7 8
S2
ON
1 2 3 4 5 6 7 8
DSL-speed 2688kbit/s*
DSL-speed 10296kbit/s**
ON
1 2 3 4 5 6 7 8
DSL-speed, 3072 kbit/s*
DSL-speed 10808kbit/s**
ON
1 2 3 4 5 6 7 8
DSL-speed, 3456 kbit/s*
DSL-speed 11320kbit/s**
ON
1 2 3 4 5 6 7 8
DSL-speed 2048kbit/s*
DSL-speed 9272kbit/s**
ON
1 2 3 4 5 6 7 8
DSL-speed, 3840 kbit/s*
DSL-speed 11832kbit/s**
ON
1 2 3 4 5 6 7 8
DSL-speed 2304kbit/s*
DSL-speed 9784kbit/s**
ON
1 2 3 4 5 6 7 8
DSL-speed, 4224 kbit/s*
DSL-speed 12344kbit/s**
ON
1 2 3 4 5 6 7 8
DSL-speed, 4608 kbit/s*
DSL-speed 13112kbit/s**
ON
1 2 3 4 5 6 7 8
DSL-speed, 4992 kbit/s*
DSL-speed 13880kbit/s**
ON
1 2 3 4 5 6 7 8
DSL-speed, 5376 kbit/s*
DSL-speed 14648kbit/s**
ON
1 2 3 4 5 6 7 8
DSL-speed 5696kbit/s*
DSL-speed 15304kbit/s**
* Standard speed S1:1 OFF
** Turbo speed S1:1 ON
