Westermo ODW-710-F1 - Manual (Page 12)

12 6651-2201
PROFIBUS DP (RS-485)
Electrical specification EIA RS-485 / EN 50 170
Data rate 9 600 bit/s, 19.2, 93.75, 187.5, 500 kbit/s, 1.5, 3, 6 and 12 Mbit/s
Data format 8 data bits, even parity, 1 stop bit, 11 bits total
Protocol PROFIBUS DP / EN 50170
Data Rate detection Yes, compliant with EN 50 170
Retiming Yes
Turn around time In accordance with EN 50 170
Transmission range ≤ 1200 m, depending on data rate and cable type (EIA RS-485)
Settings None, external termination and failsafe biasing
Protection Installation Fault Tolerant (up to ±60 V)
Isolation to Power and Status port
Connection 9-pin D-sub female
Shielded cable Not required
Conductive housing Isolated to all other circuits and housings
LED Indicators(for details see page 15)
