Type tests and environmental conditions
Environmental phenomena Basic standard Description Test levels
ESD EN 61000-4-2 Enclosure Contact: ±6 kV
Air: ±8 kV
Fast transients EN 61000-4-4 Power port ±5 kV
Signal ports ±2 kV
Earth port ±1 kV
Surge EN 61000-4-5 Power port L-E: ±0.5 kV, 12 Ω, 9 μF, 1.2/50 μs
L-L: ±0.5 kV, 2Ω, 18 μF, 1.2/50 μs
L-E: ±2 kV, 42 Ω, 0.5 μF, 1.2/50 μs
L-L: ±2 kV, 42Ω, 0.5 μF, 1.2/50 μs
L-E: ±8.4 kV, 100 Ω, 0.05/0.1 μs
L-L: ±8.4 kV, 100 Ω, 0.05/0.1 μs
Ethernet ports L-E: ±2 kV, 2 Ω
Power frequency magnetic field EN 61000-4-8 Enclosure 300 A/m; 0, 16.7, 50, 60 Hz
Pulsed magnetic field EN 61000-4-9 Enclosure 300 A/m
Radiated RF immunity EN 61000-4-3 Enclosure 20 V/m @ (80 MHz – 2.7 GHz)
1 kHz sine, 80% AM
Conducted RF immunity EN 61000-4-6 Power port 10 V, 80% AM, 1 kHz; (0.15 – 80) MHz
Ethernet ports 10 V, 80% AM, 1 kHz; (0.15 – 80) MHz
Earth port 10 V, 80% AM, 1 kHz; (0.15 – 80) MHz
Radiated RF emission EN 55022 Enclosure Class B
FCC Part 15 Class B
Conducted RF emission EN 55022 Power port Class B
Ethernet ports Class B
Dielectric strength EN 60950-1 Power port
to all other ports 1.5 kV ACrms, 50 Hz, 1 min
Fast Ethernet ports
to all other ports 1.5 kVACrms, 50 Hz, 1 min
Gig Ethernet ports
to all other ports 500 VACrms, 50 Hz, 1 min
Environmental
Temperatures Operating –40 to +70°C (–40 to +158°F)*
Storage and transport –50 to +85°C (–58 to +185°F)
Humidity Operating 5 to 95% relative humidity
Storage and transport 5 to 95% relative humidity
Altitude Operating 2 000 m / 70 kPa
Service life Operating 15 years
MTBF Viper-012
636,000 hours
MIL-C217F2, GB, 25°C (+77°F)
Viper-112/212
554,000 hours
Viper-112-T3G/212-T3G
484,000 hours
Vibration IEC 60068-2-6
(sine) Non operating long
life simulation 7.9 m/s² (RMS) 5 – 150 Hz
IEC 60068-64
(random) Operating 1 m/s² (RMS) 5 – 150 Hz
Shock IEC 60068-2-27 Operating 10 g, 30 ms
20 g, 11 ms
100 g, 6 ms
Bump IEC 60068-2-27 Operating 10 g, 11 ms
Enclosure EN 60950-1 Zinc Fire enclosure
Dimension W x H x D
With connectors See "Dimensions" chapter for details
Weight 1.4 kg
Degree of protection EN 60529 Enclosure IP67**
Cooling Convection
* Refer to “Safety” section
** Provided all connectors are connected with IP67 cabling or fitted with protective caps (delivered with the unit),
tightened to the specified torque
