11. iPod OPERATION
This unit is equipped with iPod Ready function which allow end user to have direct control of the
iPod on the front panel control button and display iPod song information on the unit's LCD display.
Please read below for more details operation
iPod Compatibility Chart
This unit is support following iPod software version
iPod 1G Not Supported
iPod 2G Not Supported
iPod 3G Firmware Version 2.2
iPod Mini All versions
iPod 4G All versions
iPod Photo All versions
iPod Nano All versions
iPod 5G(Video) All versions
Connect the iPod to this unit
About Video File
This unit can support iPod Video display output feature, however it is NOT ABLE to select any
VIDEO FILE OR VIDEO ALBUM which contained in the iPod Video. This unit will only automatically
select Music Album or File regardless the connected Video iPod last playing is a Video File or
Album. If user want to select and playback a video file on the iPod Video, Long press
“AS/PS”button for more than 3 seconds to de-activates the front panel control iPod feature. After
the LCD display “iPod Video”, the iPod now is controllable and user can select the desire playback
video file on iPod itself. Once selected a video it will automatically display on the unit thru the video
output.
Turning iPod Power On and Off
The iPod power turns on automatically as soon as it is connected to the 30 Pin Connector and as
long as the vehicle's ignition is turned ON. The iPod power can be turned OFF by removing the
iPod from the 30 Pin Connector or if the vehicle's ignition is turned OFF. Under this condition the
iPod will go into pause mode and goes into sleep mode about 2 minutes later
While the iPod is connected, the power cannot be turned on or off from the iPod itself.
“ ” to disconnect will be shown in the iPod's display while it is connected to the unit . Tips
iPod Battery Charging
While connected to the unit, the iPod will automatically start re-charging as long as the vehicle's
ignition key is turn to ACC or ON.
OK to disconnect
iPod
iPod iPod
mini
iPod
nano
HEAD UNIT
8 Din iPod Ready Cable
iPod Cable
E - 17
iPod
Video
