Chapter 2 - Basic Operations
20
4. Input time code
00:00:03:22 ................For PAL/NTSC NDF (Non Drop Frame)
* A colon is used between seconds and frames as a delimiter.
00:00:03;22 ................For NTSC DF (Drop Frame)
* A semicolon is used between seconds and frames as a delimiter.
--:--:--:-- ......................No DV signal output
* Free-run time code is used during built-in color bar output or when time code is
not input.
• DV ANALOG mode
DVCAM 32k
PLAY 00:00:00;00
1. Video input
Displays the video source.
3. 9-pin remote control deck status
Displays the status of the remote control deck.
4. Input time code
Displays the time code.
2. Audio format
Displays the audio status.
1. Video input
DVCAM ......................DVCAM signal is input.
DV ...............................DV signal is input.
----- ..............................No DV signal detected.
2. Audio format
48k ..............................The DV audio signal input is 48kHz, 16 bit.
44k ..............................The DV audio signal input is 44.1kHz, 16 bit.
32k ..............................The DV audio signal input is 32kHz, 16 or 12 bit.
----- ..............................No DV signal detected.
3. 9-pin remote control deck status
If blank ........................9-pin remote control is not in use.
NoDevice ....................Can’t find deck. Check cable connection.
NoCASETTE ...............No tape in deck.
STOP ..........................Deck is stopped.
PLAY ...........................Deck is playing.
STILL ..........................Deck is paused.
F.FWD .........................Deck is fast-forwarding.
REW ............................Deck is rewinding.
REC .............................Deck is recording.
SHUTTLE ....................Deck is shuttling.
