Chapter 2 - Basic Operations
21
4. Input time code
00:00:03:22 ................For PAL/NTSC NDF (Non Drop Frame)
* A colon is used between seconds and frames as a delimiter.
00:00:03;22 ................For NTSC DF (Drop Frame)
* A semicolon is used between seconds and frames as a delimiter.
--:--:--:-- ......................No DV signal input
* Free-run time code is used during built-in color bar output or when time code is
not input.
Main Screen 2
This screen shows the information on the current settings.
GENLOCK:enable
REMOTE:enable NTSC
1. External synchronization enabled/disabled
Displays the current setting of the external synchronization.
2. 9-pin remote enabled/disabled
Displays the current setting of the 9-pin remote.
3. Video standard
Displays the current video standard.
1. External synchronization enabled/disabled
disable ........................External synchronization function is disabled.
enable .........................External synchronization function is enabled.
advanced ....................External synchronization function in the “perfect sync mode” is
enabled.
2. 9-pin remote enabled/disabled
disable ........................9-pin remote control function is disabled.
enable .........................9-pin remote control function is enabled.
3.Video standard
NTSC ..........................ADVC700 operates in NTSC mode.
PAL .............................ADVC700 operates in PAL mode.
SECAM .......................ADVC700 operates in SECAM mode.
