June 10, 2008 K2 ASI Media Client User Manual 61
SNMP
System and Network Management Protocol.
Status Bar
Displays status and error messages.
System Layer
The system layer is the transport stream with program data and associated metadata
that describes the composition and organization of the transport stream. MPEG-2
system layer information includes synchronization bytes, PID numbers, scrambling
information, and other indicators, including the start of the transport packet payload.
Transport packets can be PES packet, a PSI table, or other private data. ATSC and
DVB transport streams are MPEG-2 compatible because the required ATSC and
DVB system layer data are MPEG-2 private data structures.
See the appropriate MPEG-2, DVB, or ATSC standards for more information.
Widescreen Mode
An aspect ratio of 16:9, as opposed to an aspect ratio of 4:3.
