General Purpose I/FConnector
8 Inputs trigger switcher functions
8 Outputs trigger external devices
PGM KEY OUT 2 J24
INPUT 4 J4
INPUT 8 J8
INPUT 12 J12
INPUT 16 J16
PGM KEY OUT 1 J20
GPI TTY/TALLY
CONTROL
PANEL
MODEM DPM EDITOR
J28 J27
J29
J25 J26
PGM
PVW
J33
J36
J34
J37
J35
J38
U
U
V
V
J31 J30 J32
J39
Y
ANALOG
OUTPUTS
Y
GRASS VALLEY GROUP
MODEL 1000
VOLTAGE: 100–240VAC ~
CURRENT: 4A
FREQUENCY: 50–60HZ
5A FUSE
& SPARE
EXT. REF. INPUT
(LOOPING)
Program Luminance Key
Component Digital Outputs
Program and Preview Analog
Component Video Outputs
(Betacam, SMPTE, or EBU-N10)
AC Power Input
100-240 Vac, 50–60 Hz
.99 Power Factor Correction
400 Watts Maximum
External Reference
Analog Color Black
NTSC or PAL
Video Input
Panel-to-Frame
Connection
Terminal and
Tally Connector
Provides one tally for
each input. Also accepts
a VT-100 compatible
terminal or pc
Editor Serial I/O Port
Digital Picture
Manipulator
Serial I/O Port
Modem
Serial I/O Port
accepts a modem for
remote service by GVG
CAUTION– RISK OF FIRE
REPLACE FUSE AS MARKED
100V–240V 5A F 250V
Modem J30 Female 9-pin D
1 DCD / GND
2 TX / TX -
3 RX / RX +
4 DTR / GND
5 GND / GND
RS232 / RS422 RS232 / RS422
6 DSR / GND
7 RTS / TX +
8 CTS / RX -
9 RI / GND
DPM J31 & Editor J32 Female 9-pin D
1 NC / GND
2 TX / TX -
3 RX / RX+
4 NC / GND
5 GND / GND
RS232 / RS422 RS232 / RS422
6 NC / GND
7 NC / TX +
8 NC / RX -
9 NC / GND
TTY/Tally J28 Female 25-pin D
1 GND
2 TERM TX1 A1
3 TERM RX1 A1
4 GND
5 TALLY 16
6 GND
7 GND
8 TALLY 15
9 GND
10 TALLY 13
11 TALLY 14
12 TALLY 11
13 TALLY 12
14 TALLY 9
15 TALLY 10
16 TALLY 7
17 TALLY 8
18 TALLY 5
19 TALLY 6
20 GND
21 TALLY 4
22 TALLY 3
23 TALLY 2
24 TALLY 1
(COM)—25 TALLY 0
Control Panel J29 Female 15-pin D
1 No Connection (NC)
2 NC
3 NC
4 Lamp +14V
5 Lamp +14V
6 Panel +9V
7 +14V Sense -
8 NC
9 Receive -
10 Receive +
11 Data Common
12 Data Common
13 Transmit +
14 Transmit -
15 +14V Sense +
1 GPI IN0 A1(COM)
21 NC
GPI J27 Female 25-pin D
2 GPI IN1 A1
3 GPI IN2 A1
4 GPI IN3 A1
5 GPI IN4 A1
6 GPI IN5 A1
7 GPI IN6 A1
8 GPI IN7 A1
9 GPI IN8 A1
10 GND
11 GND
12 GPI OUT8 A1
13 GPI OUT7 A1
14 GPI OUT6 A1
15 GPI OUT5 A1
16 GPI OUT4 A1
17 GPI OUT3 A1
18 GPI OUT2 A1
19 GPI OUT1 A1
(COM)—20 GPI OUT0 A1
22 NC
23 NC
24 NC
25 NC
Editor Relay
To
J27 pin 1
GPI IN0 A1 (COM)
To
J27 pin 9
GPI IN 8 A1
GPI Input Connection Example
Editor relay closes and triggers
switcher GPI input
•
PUT MODULE
PUT MODULE
PUT MODULE
PUT MODULE
PUT MODULE
PUT MODULE
To
J28 pin 5
TALLY 16
Tally and GPI Output Connection Example
Switcher functions trigger tally/GPI relay
closures, which in turn can trigger
events in external devices.
Camera Head Camera
Control
Unit
Tally Lamp
Tally In GND
To
J28 pin 25
TALLY 0
(COM)
•
10.66 in.
(271 mm)
0.83 in.
(21 mm)
16.57 in. (421 mm)
17.42 in. (443 mm)
Side View
Front View
27.71 in. (704 mm)
29.00 in. (737 mm)
Tub
Lower Panel Surface
Splash Panel
Display
23.28 in.
(591 mm)
Note: Leave 6 inches (152 mm)
of space behind the panel for
cable connections.
2.23 in.
(57 mm)
17.36 in. (441 mm)
Control Panel Installation
The control panel consists of a single unit which you can place on a desktop or flush mount in a con-
sole. Be sure to leave room behind the panel for making cable connections and above the panel for
opening the lid.
Desktop Mount
