121
NV9649
User’s Guide
Menus under the LCD XY Model
This is the menu that appears when you press a menu button and the panel is operating under
the LCD XY model:
There are 4 submenus:
Software version User Panel LCD Control
You can always use the ‘Exit’ button at the right to leave the menu or a submenu.
Software Versions
 The software versions submenu is available under all 3 behavioral models.
The software versions submenu appears first when you press the ‘Software Versions’ button:
Press ‘Exit’ to leave the submenu.
User
 The user submenu is available under all 3 behavioral models.
The ‘User’ submenu merely displays the configured user ID. (You cannot change it.)
Panel
 The panel submenu is available under all 3 behavioral models.
SOFTWARE SOFTWARE
VERSIONS VERSIONS USER
USER PANEL PANEL
LCD LCD
CONTROL CONTROL
EXIT EXIT
BOOT BOOT
SV1171- SV1171-
000000 000000
APP APP
SV0000- SV0000-
000000 000000
SERVER SERVER
SV0921- SV0921-
06 06
EXIT EXIT
USER USER USER ID USER ID
01 01
EXIT EXIT
