Serial Digital I/O Upgrade Installation
24 Serial Digital I/O Upgrade Installation
Installation Verification
Verification for installation of the serial digital I/O board consists of ensuring that
the system recognizes the board. Use the Diagnostics window, which lists all
installed and recognized boards, to see if the system recognizes the board. To
check for recognition of the added serial digital I/O in a PDR 200, for example:
1. From the Windows NT 4.0 desktop, open the Diagnostics window by
choosing Start | Programs | PDR Debug Tools | PDR Diagnostics .
2. On the left side of the window, ensure that the additional serial digital I/O
appears at slot J15 or wherever the board was installed (see Figure 6 for an
example).
Figure 6. Diagnostics window board recognition example for PDR204D
Slot J1
Slot J2
Slot J3
Slot J4
Slot J5
Slot J6
Slot J7
Slot J8
Slot J9
Slot J10
Slot J11
Slot J12
Slot J13
Slot J14
Slot J15
Slot J16
Slot J17
Mother Bd
Pentium CPU
Quit
Mother Board (Rev 0)
RS422, if installed
Ref Gen (4 LTC) (Rev 0)
Serial UA (Rev 1)
Non-EISA slot
SMCA010
Serial UA (Rev 1)
ASPB (Rev 1)
Master EDR (Rev 0)
Slave EDR (Rev 0)
BUS4202
Fibrechannel I/F (Rev 0)
Mix Effects (Rev 0)
