23
Specifications
Video
Transmission Method....................................................................................................... Digital
Input Level ............................................................................................800 mV (Peak To Peak)
Input/Output Impedance.......................................................................................... 75 Ohms
Return Loss .................................>15 dB, 5 Mhz To 1.5 Ghz / >10 dB, 1.5 Ghz To 3 Ghz
Coaxial Input Equalization
Maximum Rate ................................................................................................................ 3 Gb/S
Equalization At 3 Gb/S................................................................. 300m Of Belden 1694A
Bit-Error Rate (@ -22 dBm Rx Optical Power) .............................................................. 10
-12
Jitter (Using Pathological Data Pattern) ................................................................... <0.2 UI
Transmission
Operating Wavelength ..................................... 1310 nm Or 1550 nm Optical Window
Optional CWDM available
Link Margin ................................................................................................................ Up To 22dB
Transmitter Output Power Options ........................................................................... -0 dBm
Receiver Sensitivity ...........................................................................-22 dBm/ -20 At 3 Gb/S
Optical Source ..........................................................................................................Laser Diode
Optical Detector........................................................................................................................PIN
Fiber Type................................................................................................................. Single Mode
Mechanical/Environmental
Dimensions (LxWxH) ..................................................................................... 7.5”x17.5”x1.75”
Weight, each end................................................................................................................... 5 lbs
Connectors
Electrical..................................................................................................................................BNC
Optical .........................................................................................................................................ST
Input voltage............................................................................................................... 12-18 VDC
Power consumption ......................................................................................................... <15 W
Indicators................................................... Power ON, SDI Data Presence, Optical Power
Temperature Range ...............................................................................................-20° to 55 °C
Humidity Range ..........................................................................0 to 95 % non-condensing
Compliance
Laser Safety............................................................................................................. Class 1 Laser
EMI/RFI....................................................................................Complies with IEC/EN 60825-1
Certifications ..........................................................................................................................RoHS
