121
SPECIFICATIONS
Jetting Chart
Clutching
SPORTSMAN Forest 500
Transmission and Gears High/Low/Neutral/Reverse/Parking
Driving System Type Automatic PVT (POLARIS Variable Transmis-
sion)
Front Suspension MacPherson strut with 8.2" (21 cm) travel
Rear Suspension Progressive rate with 9.5" (24 cm) travel
Gear Reduction, Low 23.91:1
Gear Reduction, Reverse 21.74:1
Gear Reduction, Forward 10.57:1
Drive Ratio, Front 3.82:1
Tires Type Front Off Road Style, Deep Tread Design, size 26x8-14
/ 7 psi Pressure
Tires Type Rear Off Road Style, Deep Tread Design, size 26x10-
14 / 5 psi Pressure
Brakes, Front/Rear Single-Control handlebar hydraulic disc on all
wheels
Brakes, Auxiliary Foot-Activated Hydraulic Disc on all wheels
Parking Brake Hydraulic lock, all wheel, Mechanical on Gear-
box
Hitch Rear mount for attachment of coupling devices
Winch Front permanent Installed winch with 2500 Lbs,
1,125 Kg Capacity
Headlight 2 dual beam on bumper (55/60 watt)
Taillights 8.26 watts
Brake Light 26.9 watts
Instrument Cluster LCD
ALTITUDE
Meters (Feet)
AMBIENT TEMPERATURE
Below 40
 F
(Below 5
 C)
+40
F and above
(+5
C and above)
0-1800 (0-6000) 160 155
1800-3700
(6000-12000)
152.5 147.5
Altitude Shift
Weight
Drive Clutch
Spring
Driven Clutch
Spring
Helix/Spring
Setting
Meters
(Feet)
0-1800
(0-6000)
10 WHF
PN 5632283
Blue/Green
PN 7041157
Black
PN 7041782
41-37

PN 5132344
2+2
1800-3700
(6000-12000)
10 RH
PN 5630709
Blue/Green
PN 7041157
Black
PN 7041782
41-37

PN 5132344
2+2
