Polaris 2013 BRUTUS Operators Handbook - Manual (Page 9)

9924342 9
AUXILIARY HYDRAULIC CONTROL
INSTALLING THE PTO DRIVELINE (If Equipped)
See Owner’s Manual for more information.
Auxiliary Operation:
Press switch (Item 1) to the left to
activate the female coupler. Press
switch (Item 1) to the right to activate
the male coupler.
Relieving Hydraulic Pressure:
With engine stopped (key switch ON)
and attachment flat on ground, move
auxiliary hydraulic switch (Item 1) to
the right and left several times.
NA5909
1
TIP: The PTO has a rated speed of
2000 rpm.
1. Install the attachment on the
interface. See Page 8.
2. Connect the PTO driveline (Item 1)
to the utility vehicle PTO shaft.
TIP: The PTO driveline must have
a means to retain it to the
attachment PTO shaft. Make
sure the driveline is of adequate
length and that the u-joints are
in the correct phase.
NA5913
1
IMPORTANT
Do not exceed the rated attachment
PTO speed of 2000 rpm. Damage to
the attachment could occur from over
speeding. Disengage PTO for road
travel.
WARNING
AVOID INJURY OR DEATH
•
Keep PTO shields and all guards
in place
.
•
Keep hands, legs, feet and
clothing away
.
•
Replace damaged or missing
shields and guards
.
