42
Specifications
ND 281: Dimensions in mm/inches
35
1.43"
172 ± 0.2
6.77" ± .008"
33.5
1.37"
224 8.82"
140
± 0.2
5.51"
± .008"
239
9.41"
325 12.8"
X
HEIDENHAIN
15 °
84.6 3.33"
6
.24"
M4 x 6
M4 x .24"
X
X1
X31 X41
ND 281 A Id. Nr. 283 481 ..
ND 281 V Id. Nr. 322 353 ..
X
X1
X31 X41
