3 smart.turn units for the y axis – HEIDENHAIN SW 54843x-02 DIN Programming User Manual
Page 15
HEIDENHAIN MANUALplus 620, CNC PILOT 640
15
3.1 Units—Drilling in the Y axis ..... 160
"ICP drilling, Y axis" unit ..... 160
"ICP tapping, Y axis" unit ..... 161
"ICP boring/countersinking, Y axis" unit ..... 162
3.2 Units—Predrilling in Y axis ..... 163
"Predrill, contour mill, ICP in XY plane" unit ..... 163
"Predrill, pocket mill, ICP in XY plane" unit ..... 164
"Predrill, contour mill, ICP in YZ plane" unit ..... 165
"Predrill, pocket mill, ICP in YZ plane" unit ..... 166
3.3 Units—Milling in Y axis ..... 167
"ICP contour milling in XY plane" unit ..... 167
"ICP pocket milling in XY plane" unit ..... 168
"Single-surface milling, XY plane" unit ..... 169
"Centric polygon milling, XY plane" unit ..... 170
"Engraving in XY plane" unit ..... 171
"Deburring in XY plane" unit ..... 172
"Thread milling in XY plane" unit ..... 173
"ICP contour milling in YZ plane" unit ..... 174
"ICP pocket milling in YZ plane" unit ..... 175
"Single-surface milling, YZ plane" unit ..... 176
"Centric polygon milling, YZ plane" unit ..... 177
"Engraving in YZ plane" unit ..... 178
"Deburring in YZ plane" unit ..... 179
