HEIDENHAIN iTNC 530 (34049x-08) ISO programming - Manual (Page 576)

576 MOD functions
1
7.6 Ether
n
et int
e
rf
ace
OPTIONS for
FILESYSTEMTYPE
=smb for direct
connection to
Windows networks
Data without spaces, separated by commas,
and written in sequence. Switch between
upper and lower case letters.
ip=
: IP address of PC to which the TNC is to
be connected
username=
: User name under which the TNC
is to log on
workgroup=
: Work group under which the
TNC is to log on
password=
: Password with which the TNC is
to log on (up to 80 characters)
AM Definition of whether the TNC upon switch-
on should automatically connect with the
network drive.
0: Do not automatically connect
1: Connect automatically
The entries username, workgroup and password in the
OPTIONS column may not be necessary in Windows 95
and Windows 98 networks.
With the ENCODE PASSWORD soft key, you can encode
the password defined under OPTIONS.
Setting Meaning
