Accessories
■
One HR 550 FS portable wireless handwheel with display or
■
One HR 520 portable handwheel with display, or
■
One HR 420 portable handwheel with display or
■
One HR 410 portable handwheel, or
Electronic handwheels
■
One HR 130 panel-mounted handwheel, or
■
Up to three HR 150 panel-mounted handwheels via HRA 110
handwheel adapter
■
TS 220: triggering 3-D touch probe with cable connection, or
■
TS 440: 3-D touch trigger probe with infrared transmission
■
TS 444: Battery-free 3-D touch trigger probe with infrared transmission
■
TS 640: 3-D touch trigger probe with infrared transmission
■
TS 740: High-precision 3-D touch trigger probe with infrared
transmission
Touch probes
■
TT 140: 3-D touch trigger probe for tool measurement
■
TT 449: 3-D touch trigger probe for tool measurement with infrared
transmission
Hardware, options
■
1st additional axis for 4 axes plus spindle
■
2nd additional axis for 5 axes plus spindle
Software option 1
(option number 08)
Rotary table machining
■
Programming of cylindrical contours as if in two axes
■
Feed rate in distance per minute
Coordinate transformation
■
Working plane, tilting the ...
Interpolation
■
Circle in 3 axes with tilted working plane (spacial arc)
Software option 2
(option number 09)
■
Motion control with minimum jerk
■
3-D tool compensation through surface normal vectors
■
Using the electronic handwheel to change the angle of the swivel head
during program run without affecting the position of the tool point.
(TCPM =
T
ool
C
enter
P
oint
M
anagement)
3-D machining
■
Keeping the tool normal to the contour
■
Tool radius compensation perpendicular to traversing and tool direction
Interpolation
■
Linear in 5 axes (subject to export permit)
Touch probe function software option
, (option number 17)
■
Compensation of tool misalignment in manual mode
■
Compensation of tool misalignment in automatic mode
■
Datum setting in manual mode
■
Datum setting in automatic mode
■
Automatic workpiece measurement
Touch probe cycles
■
Automatic tool measurement
