20.1 Overview
Fixed cycles
Cycle
number Cycle designation DEF
active CALL
active Page
7 Datum shift
■
255
8 Mirror image
■
262
9 Dwell time
■
279
10 Rotation
■
264
11 Scaling factor
■
266
12 Program call
■
280
13 Spindle orientation
■
282
14 Contour definition
■
190
19 Tilting the working plane
■
269
20 Contour data SL II
■
195
21 Pilot drilling SL II
■
197
22 Rough out SL II
■
199
23 Floor finishing SL II
■
203
24 Side finishing SL II
■
205
25 Contour train
■
208
270 Contour train data
■
210
26 Axis-specific scaling
■
267
27 Cylinder surface
■
223
28 Cylindrical surface slot
■
226
29 Cylinder surface ridge
■
229
39 Cylinder surface contour
■
232
32 Tolerance
■
283
200 Drilling
■
77
201 Reaming
■
79
202 Boring
■
81
203 Universal drilling
■
84
204 Back boring
■
87
205 Universal pecking
■
90
206 Tapping with a floating tap holder, new
■
105
207 Rigid tapping, new
■
108
208 Bore milling
■
94
209 Tapping with chip breaking
■
111
220 Polar pattern
■
179
221 Cartesian pattern
■
182
225 Engraving
■
300
