POWER: This is the main power ON/OFF switch. After switch on all of the LED’s on the fascia light
up momentarily, after a couple of seconds the LED’s indicate the previous settings used: i.e. If the
amp was last used on Channel 1 with Reverb, the Channel 1 & DEL FX LED’s will be lit. All other
control settings associated with Channel 1 will also be recalled.
INPUT JACK: Connect your guitar here. Use only good
quality cables to avoid poor sound quality.
AUX IN JACK: Use this input for CD/MP3 players to allow
you to play along to the music or use as backing. For use with
standard stereo 3.5mm jack leads. The overall volume of your
player is controlled by its own volume control.
(NOTE: This input is not muted when in the guitar tuner is in use).
AMP: These controls on CH1 & CH2 allow the user to select
from the two sets of eleven factory pre programmed amp
models.
These are not just guitar amp settings, each channel can be a compilation of amp and effect set-ups to
give some of music’s most inspirational sounds. The amp models used on each channel could be
totally different or could be the same, just with different volume/EQ settings, there is a vast choice to
suit your own style & taste.
