FRONT PANEL CONTROLS
Page
10 / 20
1
3
4
5
6
7
8
MIC/AUX IN: XLR/Jack Combo Socket input has been designed to accept both balanced (XLR) and balanced or unbalanced
(6.3 Jack) signals. (Phantom power is also supplied with the signal through the balanced XLR if your Mic. uses it). A mic,
keyboard, another guitar etc. can all be connected here. Good quality low impedance condenser or dynamic mics should
preferably be used for best results, these will ensure the best possible results from hand-held or closely mic'd instruments.
GAIN: Controls the gain level of Channel 1.
LO: Active control allowing boost and cut of the low-frequency response of Channel 1.
HI: Active control allowing boost or cut of the high frequency response of Channel 1.
REVERB: Controls the level of reverb to Channel 1.
INSTRUMENT: XLR / Jack Combo Socket input: (both balanced (XLR) and balanced or unbalanced-6.3 Jack), connect your
guitar via this socket, use only good quality instrument cable.
PAD: The pad switch allows you to reduce (or pad down) the input level from a guitar with an active pickup system, or a
particularly loud passive pickup to prevent the guitar from overloading the preamplifier.
PRESHAPE:
GAIN: Controls the gain level of Channel 2.
EQ: The four band graphic equalizer allows you to easily modify your tone and effectively ‘see’ the response you are getting.
There are four sliders covering Low, Low-Mid, High-Mid & High in the 80Hz - 3KHz range. When the slider is in the central
position the signal at that frequency is unaffected or flat. Moving the slider up or down from the centre will Boost or Cut
that frequency.
Adds an instant natural shaped EQ response with mid cut and bass+treble boost. This is ideal for many
strumming and finger picking styles.
2
9
10
LA65D
GAIN
LO
HI
REVERB
REVERB
7
1
9
3
10
4
6
0
5
8
2
7
1
9
3
10
4
6
0
5
8
2
7
1
9
3
10
4
6
0
5
8
2
7
1
9
3
10
4
6
0
5
8
2
7
1
9
3
10
4
6
0
5
8
2
7
1
9
3
10
4
6
0
5
8
2
7
1
9
3
10
4
6
0
5
8
2
7
1
9
3
10
4
6
0
5
8
2
INSTRUMENT
LA65D
ACOUSTIC
AUX IN
7
1
9
3
10
4
6
0
5
8
2
7
1
9
3
10
4
6
0
5
8
2
MIC/AUX IN
GAIN
7
1
9
3
10
4
6
0
5
8
2
7
1
9
3
10
4
6
0
5
8
2
PAD
LO
HM
LM
HI
EQUALISATION
500
25
125
ANTI-
FEEDBACK
SHIMMER
7
1
9
3
10
4
6
0
5
8
2
7
1
9
3
10
4
6
0
5
8
2
7
1
9
3
10
4
6
0
5
8
2
7
1
9
3
10
4
6
0
5
8
2
CHORUS
RATE
DEPTH
CHANNEL 1
CHANNEL 2
VOLUME
7
1
9
3
10
4
6
0
5
8
2
7
1
9
3
10
4
6
0
5
8
2
PRESHAPE
PEAK
PHASE
ON
ON
19
1
2
3
5
6
4
18
9
10
16
7
11
8
14
17
15
12
13
