EN
Copyright © 2010 VARO P a g e | 6 www.varo.com
6.3 Stopping the engine
1. Turn the fuel valve to the OFF position
2. FLYWHEEL BRAKE MODELS :
3. Release the starter control handle (located on equipment) to stop the engine.
4. Turn the control lever to the STOP position(located on equipment
1. brake cable
7 SPECIFICATIONS
Type DYM1P60FA DYM1P64FA DG600
Dry weight(kg) 12 12 14.5
Engine type 4-stroke, overhead valve, single cylinder
Displacement[Bore x
Stroke]
118cm³ - 60X42 135cm³ - 64x42mm 173cm³ - 70x45mm
Max. torque 6.5 Nm at 2600 rpm 7 Nm at 2600 rpm 9.5Nm at 2800rpm
Cooling system Forced air
PTO shaft rotation Counter clockwise
8 TUNE-UP SPECIFICATIONS
ITEM SPECIFICATION MAINTENANCE
Spark plug gap 0.028-0.031 inch
(0.7-0.8 mm) Refer to 8.8
Valve clearance (cold) IN:0.06+0.02mm
EX:0.08+0.02mm See your authorized
dealer
Other specifications No other adjustments needed
9 SERVICING YOUR ENGINE
9.1 The importance of maintenance
Good maintenance is essential for safe, economical and trouble-free operation. It will also help
reduce pollution.
WARNING
Improper maintenance, or failure to correct a problem before operation, can
cause a malfunction in which you can be seriously hurt or killed.
Always follow the inspection and maintenance recommendations and
schedules in this owner's manual.
To help you properly care for your engine, the following pages include a maintenance schedule,
routine inspection procedures, and simple maintenance procedures using basic hand tools.
