When releasing the trigger of the trigger gun, the machine automatically stops. The machine
will start again when you re- activate the trigger gun.
8.6
Multi nozzle (Fig. 8)
The pressure can for the multi nozzle be adjusted by tuning it.
WARNING: Do not do this under operation to avoid that the hand hits the
jet.
8.7
Foam Sprayer (Fig. 9)
1.
Unscrew the container (A) from the foam sprayer.
2.
Add detergent to the container (A) and screw the container to the foam sprayer.
3.
Adjust the amount of detergent with the button (B)
8.8
Patio Cleaner
The patio cleaner is a powerful accessory for cleaning patio, driveways, etc.
Attach the Patio Cleaner to the lance.
NOTE: Do not use the Patio Cleaner as a broom but let is surf smoothly over the surface
9 TECHNICAL DATA
POWXG9020
Motor TYPE
Brush motor
Pressure (Mpa)
7
Max. Pressure (Mpa)
10.5
Voltage
230V / 50Hz
Power
1500W
Flow
6 L/min
Water temperature
Max 40°C
Min. flow of water supply
360 L/h
Min. pressure water inlet
0.18 Mpa
Weight
6 kg
10 NOISE
Noise emission values measured according to relevant standard. (K=3)
Acoustic pressure level LpA
82 dB(A)
Acoustic power level LwA
99 dB(A)
ATTENTION! Wear hearing protection when sound pressure is
over 85 dB(A).
aw (Vibration)
1,0 m/s²
K = 1,5 m/s²
