13 GB
Basin Spray Shower
Attachment
Introduction
Dear Customer, you have pur-
chased a durable high quality
product manufactured by us.
Before you start the installation please read
through all of these instructions and take
note of the advice they contain. These
instructions contain important information
about installation, settings and product
care. Keep these instructions safe and if you
pass on the product to anyone else please
pass on the documentation as well.
Intended use
This product is suitable for use with all pres-
sure-resistant hot water systems such as cen-
tral heating, continuous-flow water heater,
pressure boiler etc. It is not suitable for low
pressure water heaters such as wood-burn-
ing or coal-burning domestic hot water gey-
sers, oil or gas-fired hot water geysers, or
open electrically heated cylinders. If in
doubt, please consult a plumber or heating
specialist. Any use other than that described
here, or any modification to the product, is
not permitted and may lead to damage to
persons or property. There is also the risk of
injury and loss of life. The product is for pri-
vate use only and is not intended for medi-
cal or commercial use. The manufacturer
does not accept any liability for any dam-
age caused by improper use.
Description of Parts
1 Basin Spray Shower Attachment
2 Screw
3 Wall mounting
4 Dowel
5 Push button
6 Shower hose
7 Seal for shower hose
8 Fitting connection
9 Adapter piece
10 Seal for fitting connection
11 Aerator
Technical data
Basin Spray
Shower Attachment: 180 x 33mm
(length x ø)
Shower hose: 125cm, ½” standard
connection
Fitting connection: M22 internal thread
(with adapter piece)
M24 external thread
(without adapter
piece)
Items supplied
1 Basin Spray Shower Attachment
1 Shower hose
1 Wall mounting
1 Fitting connection with adapter piece
2 Seals for shower hose
1 Seal for fitting connection
1 Screw
1 Dowel
1 Operating instructions
