SKT 2000 B1 53
5. Unpacking and setting up
1. Unpack the appliance from the
packaging.
2. Remove the transport packaging.
3. Check that the appliance shows no signs
of damage.
5.1 Assembling the appliance for set-up
on the floor
1. Screw the feet 4 to the underside of the
convector using the short screws
provided. 2 screws are inserted
diagonally per foot.
Warning! Check that there is
sufficient distance from the wall,
fixtures and other appliances.
When setting up on the floor, the
distance must be at least 0.5 m to
exclude the risk of fire.
The distance to the wall must
always be observed unless you are
using the wall hooks supplied. The
wall should not be flammable.
2. Select a location in compliance with the
safety information (see “4. Safety
instructions” on page 50).
5.2 Mounting the appliance on a wall
Caution!
• The wall must not be flammable and
should also be strong enough.
• The appliance must be at least 10 cm
above the floor so air can circulate
freely.
Note: If you are mounting the appliance
on a wall, the feet must not be screwed on.
1. Screw the wall hooks supplied securely
to a wall suitable for this purpose:
– Mark the position of the two drill holes
so that the space between the wall
hooks matches the space between the
two slots on the rear of the appliance.
– Make sure that the two drill holes are
absolutely horizontal.
– Drill a hole around 40 mm deep using
an 8 mm bit.
– Insert a wall plug in each hole.
– Screw the two wall hooks in place
using the long screws.
2. To ensure the appliance hangs vertically
on the wall, the two other wall hooks are
used here as spacers:
– Screw the two remaining wall hooks
to the underside of the appliance.
– Use the short screws for this purpose.
3. Hang the appliance from the wall hooks.
