Produktinformationen:
Bohrkronen-Set
Modell-Nr.: Z30829
Version:

08 / 2011

Stand der Informationen: 07 / 2011
Ident.-No.: Z30829072011-5

Setzen Sie die andere Bohrkrone auf den Aufnahmeschaft und
drehen Sie diese im Uhrzeigersinn fest.

Inbetriebnahme

Setzen Sie die Bohrkrone

1

,

2

immer im 90°-Winkel auf das

Werkstück. Andernfalls kann es zu einer unregelmäßigen Abnut-
zung der Schneidezähne der Bohkrone kommen.

Achten Sie darauf, dass der Zentrierbohrer

3

nicht abrutscht.

Andernfalls können Sie kein zentriertes, gleichmäßiges Loch bohren.

Lassen Sie das Werkzeug während des Bohrens nicht zum Still-
stand kommen.

Üben Sie während des Bohrens nur leichten Druck aus. Andern-
falls können das Werkzeug und / oder das Werkstück überhitzen.

Sorgen Sie für eine ausreichende Schmierung, um eine Überhitzung
von Werkzeug und Werkstück zu vermeiden und die Funktionalität
des Werkzeuges zu erhalten.

Reinigung

Reinigen Sie Bohrkronen

1

,

2

und Zentrierbohrer

3

nach jeder

Nutzung mit einem weichen, angefeuchteten Tuch. Verwenden Sie
in keinem Fall reizende Flüssigkeiten und keine Reinigungsmittel,
da diese das Werkzeug beschädigen.

Entsorgung

Die Verpackung besteht aus umweltfreundlichen Materialien.
Sie kann in den örtlichen Recyclingbehältern entsorgt werden.

Möglichkeiten zur Entsorgung des ausgedienten Produktes erfahren
Sie bei Ihrer Gemeinde- oder Stadtverwaltung.

VERBRENNUNGSGEFAHR! Sorgen Sie für eine ausreichende
Kühlung. Andernfalls kann das Werkzeug und / oder das zu bear-
beitende Material durch die Reibung überhitzen.

VORSICHT! HEISSE OBERFLÄCHEN! Das Werk-
zeug kann sich durch die Anwendung stark erhitzen. Bei
Berührung des heißen Werkzeuges können Verbrennungen

die Folge sein. Tragen Sie Schutzhandschuhe, um Verbrennungen
zu vermeiden.

Vor der Inbetriebnahme

Montage

Stecken Sie den Zentrierbohrer

3

gemäß Abbildung A in den

Aufnahmeschaft

4

.

Hinweis: Stellen Sie sicher, dass die flache Seite des Zentrier-
bohrers mit der Schraube im Aufnahmeschaft befestigt werden kann.

Drehen Sie die Schraube im Aufnahmeschaft mittels Maulschlüssel
im Uhrzeigersinn fest, um den Zentrierbohrer zu fixieren. Bei Nicht-
beachtung, kann sich das Werkzeug lösen. Verletzungen
und / oder Beschädigungen des Werkzeugs können die Folgen sein.

Stecken Sie die entsprechende Bohrkrone

1

,

2

gemäß Abbil-

dung A auf den Aufnahmeschaft und drehen Sie diese im Uhrzei-
gersinn fest.

Bohrkronen-Set in die Maschine einsetzen:

Setzen Sie den Aufnahmeschaft in das Bohrfutter der Bohrmaschine /
des Bohrhammers. Beachten Sie dazu die Bedienungsanleitung
des Herstellers.

Bohrkrone wechseln:

Drehen Sie die Bohrkrone gegen den Uhrzeigersinn vom
Aufnahmeschaft.

Lieferumfang

1 Bohrkrone 80 x 72 mm, 10 Zähne
1 Bohrkrone 60 x 72 mm, 7 Zähne
1 Zentrierbohrer 110 x 7 mm
1 Aufnahmeschaft 110 x 26 mm
1 Bedienungsanleitung

Sicherheitshinweise

LEBENS- UND UNFALLGE-

FAHR FÜR KLEINKINDER UND KINDER! Lassen
Sie Kinder niemals unbeaufsichtigt mit dem Verpackungs-

material. Es besteht Erstickungsgefahr. Kinder unterschätzen häufig
die Gefahren. Halten Sie Kinder stets vom Produkt fern.

Ziehen Sie vor jedem Werkzeugwechsel den Netzstecker der

Bohrmaschine aus der Steckdose.

Lesen Sie vor der Inbetriebnahme einer Bohrmaschine die jeweilige

Bedienungsanleitung. Andernfalls können Sie sich und / oder an-
dere Personen verletzen und / oder das Werkzeug beschädigen.

Tragen Sie eine Schutzbrille!

Tragen Sie Schutzhandschuhe!

VORSICHT! Beachten Sie die Drehzahlempfehlungen. Das
Arbeiten mit falschen Drehzahlen kann Verletzungen und / oder
Beschädigungen des Werkzeugs zur Folge haben.

VORSICHT! VERLETZUNGSGEFAHR! Stellen Sie sicher, dass

alle Teile unbeschädigt und sachgerecht montiert sind. Bei unsach-
gemäßer Montage besteht Verletzungsgefahr. Beschädigte Teile
können die Sicherheit und Funktion beeinflussen.

Bohrkronen-Set

Einleitung

Machen Sie sich vor der ersten Inbetriebnahme mit den
Bohrkronen vertraut. Lesen Sie hierzu die nachfolgende
Bedienungsanleitung. Bewahren Sie diese Anleitung auf.

Machen Sie sich außerdem mit den Funktionen der Elektrowerkzeuge,
in die Sie die Bohrkronen einsetzen, vertraut und informieren Sie sich
über den Umgang mit Elektrowerkzeugen. Händigen Sie alle Unterlagen
bei Weitergabe der Bohrkronen an Dritte aus.

Bestimmungsgemäßer Gebrauch

Die Bohrkronen sind zum Bohren in Ziegel und vergleichbares Mauer-
werk bestimmt. Sie sind für alle handelsüblichen Bohrhämmer mit
Werkzeugaufnahme nach dem SDS-plus-System (auch Bosch) geeignet.
Jede andere Verwendung oder Veränderung der Bohrkronen gilt als
nicht bestimmungsgemäß und birgt erhebliche Unfallgefahren. Nicht
zum gewerblichen Gebrauch. Für aus bestimmungswidriger Verwen-
dung entstandene Schäden übernimmt der Hersteller keine Haftung.

Teilebeschreibung

1

Bohrkrone 80 x 72 mm, 10 Zähne

2

Bohrkrone 60 x 72 mm, 7 Zähne

3

Zentrierbohrer 110 x 7 mm

4

Aufnahmeschaft 110 x 26 mm

Technische Daten

Bohrkrone

1

:

80 x 72 mm, 10 Zähne, Bohrtiefe: 50 mm

Bohrkrone

2

:

60 x 72 mm, 7 Zähne, Bohrtiefe: 50 mm

Max. Nenndrehzahl:

320 U / min.

Last Information Update: 07 / 2011
Ident.-No.: Z30829072011-5

Use

Always place the core drill bit

1

,

2

at an angle of 90° to the

workpiece. Otherwise uneven wear of the teeth on the core drill
bit may occur.

Ensure that the pilot drill bit

3

does not slip. Otherwise the resulting

hole may be off-centre or unevenly drilled.

Do not allow the tool to come to a standstill while you are drilling.

Use only light pressure when you are drilling. Otherwise the tool
and / or the workpiece may overheat.

Use adequate lubrication to prevent overheating of the tool and
the workpiece and to keep the tool working properly.

Cleaning

Clean the core drill bits

1

,

2

and the pilot drill bit

3

with a soft,

moist cloth after each use. Never use harsh liquids or cleaning
agents as they may damage the tool.

Disposal

The packaging consists of environmentally friendly materials.
It can be disposed of at your local recycling facility.

Contact your local refuse disposal authority for more details of how to
dispose of your worn-out product.

Product description:
Core Drill Set
Model No.: Z30829
Version:

08 / 2011

RISK OF BURNS! Please ensure there is adequate cooling! Oth-
erwise the core drill bit assembly and / or the material being cut
may overheat due to friction.

CAUTION! HOT SURFACES! The tool may become
very hot during use. You may suffer a burn injury by contact
with a hot tool. To avoid burn injury wear protective gloves.

Before first use

Assembly

Insert the pilot drill bit

3

into the adapter

4

in accordance with Fig. A.

Note: Check that the flat side of the pilot drill can be fastened with the
screw in the adapter.

Tighten the screw in the adapter by turning the screw clockwise
using an open spanner to fix the pilot drill bit in place. If this is not
done properly, the attached tool may become loose. Failure to
observe this advice may result in damage to the tool and / or injury.

Place the required core drill bit

1

,

2

on to the adapter in

accordance with Fig. A and turn the core drill bit clockwise.

Inserting the core drill bit assembly into the electric drill:

Insert the adapter into the chuck on the electric drill / hammer drill.
Observe the requirements of the operating instructions supplied with
the electrical power tool.

Changing the core drill bit:

Turn the core drill bit anticlockwise off the adapter.

Place the other core drill bit on to the adapter and turn the core
drill bit clockwise.

Included items

1 Core drill bit 80 x 72 mm, 10 teeth
1 Core drill bit 60 x 72 mm, 7 teeth
1 Pilot drill bit 110 x 7 mm
1 Adapter 110 x 26 mm
1 Operating instructions

Safety advice

DANGER OF LOSS OF LIFE

AND ACCIDENT TO INFANTS AND CHILDREN!
Never leave children unsupervised with the packaging

materials. Danger of suffocation. Children often underestimate
risks. Always keep children away from the product.

Before changing any tool, pull the mains plug of the drill out of the

mains socket.

Read through the operating instructions before using a drill for

the first time. This is intended to ensure that you or others are not
injured and / or no damage occurs to the tool.

Wear protective glasses!

Wear protective gloves!

CAUTION! Take note of the recommended speeds. Working at
the wrong speed can lead to injury and / or damage to the core
drill bit assembly.

CAUTION! DANGER OF INJURY! Please ensure that no
parts are damaged and that all parts are correctly assembled.
Incorrect assembly or fitting may lead to injury. Damaged parts
can adversely affect safety and proper function.

Core Drill Set

Introduction

Before using the core drill bit set for the first time, please
make yourself familiar with the way it works. To help you do
this, please read the accompanying operating instructions.

Keep these instructions in a safe place. In addition please make your-
self familiar with the functions of the electrical power tools into which
you intend to insert the core drill bit assembly and ensure that you
know how to handle electrical power tools in general. If you pass the
core drill bit set on to anyone else, please ensure that you also pass
on all the documentation.

Proper use

The core drill bit set is suitable for drilling into brick and comparable
masonry. It is suitable for use with all commercially available hammer
drills with chucks complying with the SDS-plus-System (also Bosch). Any
other use or modification to the core drill bit set shall be considered as
improper use and could give rise to considerable dangers. Not suitable
for commercial use. The manufacturer accepts no liability for loss or
damage arising from improper use.

Description of parts and features

1

Core drill bit 80 x 72 mm, 10 teeth

2

Core drill bit 60 x 72 mm, 7 teeth

3

Pilot drill bit 110 x 7 mm

4

Adapter 110 x 26 mm

Technical data

Core drill bit

1

:

80 x 72 mm, 10 teeth, drilling depth: 50 mm

Core drill bit

2

:

60 x 72 mm, 7 teeth, drilling depth: 50 mm

Max. no-load speed:

320 rpm

GB/MT

GB/MT

GB/MT

GB/MT

GB/MT

Informações sobre o produto:
Conjunto de mandris
N.º do modelo: Z30829
Versão:

08 / 2011

Data das informações: 07 / 2011
N.º de ident.: Z30829072011-5

Colocação em funcionamento

Coloque a broca de coroa

1

,

2

sempre num ângulo de 90° sobre

a peça a trabalhar. Caso contrário, pode ocorrer um desgaste
irregular dos dentes de corte da broca de coroa.

Tenha cuidado para que a broca de centragem

3

não deslize.

Caso contrário, nгo й possível efectuar um orifício centrado e
uniforme.

Durante a perfuração, nunca deixe a ferramenta parar na

totalidade.

Exerça apenas uma pressão ligeira durante a perfuração. Caso

contrário, a ferramenta e / ou a peça a trabalhar podem sobrea-
quecer.

Assegure uma lubrificação suficiente para evitar o sobreaqueci-

mento da ferramenta e da peça a trabalhar e para manter a boa
funcionalidade da ferramenta.

Limpeza

Limpe as brocas de coroa

1

,

2

e a broca de centragem

3

após cada utilização com um pano macio e húmido. Nunca utilize
líquidos abrasivos ou detergentes, pois estes danificam a ferramenta.

Eliminação

A embalagem é composta por materiais recicláveis. Estes
podem ser depositados nos ecopontos locais.

Poderá obter informações relativas à eliminação do produto usado
junto das autoridades locais competentes.

PERIGO DE QUEIMADURAS! Assegure uma boa refrigeração.

Caso contrário, a ferramenta e / ou o material a trabalhar podem
sobreaquecer devido à fricção.

CUIDADO! SUPERFÍCIES QUENTES! A ferramenta
pode aquecer durante a utilização. Se tocar na ferra-
menta quente pode sofrer queimaduras. Use luvas de

protecção para evitar queimaduras.

Antes da colocação em funcionamento

Montagem

Coloque a broca de centragem

3

na haste de encaixe

4

,

conforme ilustrado na figura A.
Nota: Assegure que o lado plano da broca de centragem pode
ser fixo com o parafuso na haste de alojamento.

Aperte o parafuso na haste de encaixe, rodando com uma chave

inglesa no sentido dos ponteiros do relógio, para fixar a broca de
centragem. Caso contrário, a ferramenta pode soltar-se. Podem
ocorrer ferimentos e / ou danos na ferramenta.

Coloque a respectiva broca de coroa

1

,

2

na haste de encaixe,

conforme ilustrado na figura A, e aperte-a, rodando no sentido
dos ponteiros do relógio.

Colocar o conjunto de brocas de coroa na máquina:

Introduza a haste de encaixe no porta-brocas do berbequim /

martelo perfurador. Respeite o manual de instruções do fabricante.

Substituir a broca de coroa:

Retire a broca de coroa da haste de encaixe, rodando no sentido

contrário ao dos ponteiros do relógio.

Coloque a outra broca de coroa na haste de encaixe e aperte-a,

rodando no sentido dos ponteiros do relógio.

PT

PT

PT

© by ORFGEN Marketing

IAN 64751
Milomex Ltd.
c / o Milomex Services
Hilltop Cottage
Barton Road
Pulloxhill
Bedfordshire
MK45 5HP
UK

64751_pow_Bohrkronen-Set_content_LB5.indd 2

13.07.11 17:31

Advertising
