Mounting the tube attachment
The tube attachment is intended for clamping tubes with a diameter
of 38 - 43 mm.
1. Release the hexagonal socket head screw
3
at the end of
the spindle using the supplied hexagon socket screw key
12
.
2. Turn the vice jaws tommy bar
9
anticlockwise until the
spindle
10
is turned out of the rear jaw
2
.
3. Using the supplied hexagon socket screw key
12
, release the
hexagonal socket head screw
8
on the underside of the vice
base
11
and remove the spindle
10
from the vice.
4. Now that the hexagonal socket head screw
4
is accessible,
remove it and take the vice base off the ball joint
5
.
5. Place the tube attachment
13
on to the ball joint
5
and
fasten it in place with the hexagonal socket head screw
4
.
6. Turn and tilt the ball joint
5
to achieve the right position.
Cleaning and care
Clean the product with a dry, fluff-free cloth.
Never use aggressive or corrosive cleaning agents, as they
may damage the product.
Disposal
The packaging is made entirely of recyclable materials,
which you may dispose of at local recycling facilities.
Contact your local refuse disposal authority fo r more details of
how to dispose of your worn-out product.
