Use of the stove
Code Message on display Function Key sequence
UT 01 OFF Activating timer; use Keys 1
and 2 to change the current
day To move on to the next
function press Key 3
UT 02 OFF Setting the hour Keys 1-2 to adjust
Key 3 to confirm
UT 03 OFF Setting the minutes Keys 1-2 to adjust
Key 3 to confirm
UT 05 OFF Stove lighting time
PROGRAM 1 Keys 1-2 to adjust
Key 3 to confirm
UT 06 OFF Stove shutdown time
PROGRAM 1 Keys 1-2 to adjust
Key 3 to confirm
UT 07 OFF Days active
PROGRAM 1 Key 2 to scroll through days.
Key 1 for ON/OFF
UT 08 OFF Stove lighting time
PROGRAM 2 Keys 1-2 to adjust
Key 3 to confirm
UT 09 OFF Stove shutdown time
PROGRAM 2 Keys 1-2 to adjust
Key 3 to confirm
UT 10 OFF Days active
PROGRAM 2 Key 2 to scroll through days.
Key 1 for ON/OFF
UT 11 OFF Stove lighting time
PROGRAM 3 Keys 1-2 to adjust
Key 3 to confirm
UT 12 OFF Stove shutdown time
PROGRAM 3 Keys 1-2 to adjust
Key 3 to confirm
UT 13 OFF Days active
PROGRAM 3 Key 2 to scroll through days.
Key 1 for ON/OFF
UT 14 OFF Stove lighting time
PROGRAM 4 Keys 1-2 to adjust
Key 3 to confirm
UT 15 OFF Stove shutdown time
PROGRAM 4 Keys 1-2 to adjust
Key 3 to confirm
UT 16 OFF Days active
PROGRAM 4 Key 2 to scroll through days.
Key 1 for ON/OFF
Programming the timer
ATTENTION !
Code UT 04 is not used for programming the timer. It is reserved for the exclusive
use of the installer or qualified MCZ technician via an access key. When scrolling
through the menu, always skip this code.
All the programs lighting times (see UT05-UT08-UT11-UT14) must be included between a
minimum of 0:00 and a maximum of 23:40.
All the programs shutdown times (see UT06-UT09-UT12-UT15) must be later than the
corresponding lighting time and must have a maximum time of 23:50.
See the example below
35
Initial display shows the word
OFF in all fields
If UT05 is Then UT06 is between
7:30 7:40 and 23:50
17:00 17:10 and 23:50
If UT05 is Then UT06 is between
21:20 21:30 and 23:50
23:40 23:50
