Model PD6060 Dual-Input Process Meter

Instruction Manual

99

MOUNTING DIMENSIONS

1.76"

(45 mm)

0.59"

(15 mm)

4.77"

(121 mm)

2.45"

(62 mm)

5.05"

(128 mm)

Figure 21. Meter Dimensions - Side View

3.61"

(92 mm)

4.17"

(106 mm)

4.68"

(119 mm)

Figure 22. Meter Dimensions - Top View
