SG-500 VPN Security Gateway User’s Manual
- 134 -
STEP 15 . Select Remote Gateway-Fixed IP or Domain Name In To Destination list and enter the IP
Address.
IPSec To Destination Setting
STEP 16 . Select Preshare in Authentication Method and enter the Preshared Key. (The maximum
Preshared Key is 100 bytes).
IPSec Authentication Method Setting
STEP 17 . Select ISAKMP Algorithm in Encapsulation list. Choose the Algorithm when setup connection.
Please select ENC Algorithm (3DES/DES/AES), AUTH Algorithm (MD5/SHA1), and Group (GROUP1,
2,5). Both sides have to choose the same group. Here we select 3DES for ENC Algorithm, MD5 for
AUTH Algorithm, and GROUP1 for group.
IPSec Encapsulation Setting
