Samsung WM55B Flip Pro 55" 4K Interactive Touchscreen LED Display - Manual (Page 28)

28
Brush Mode
Screen elements
1 1
2 3 4 5 6 7
Brush Mode Palette Select Undo Redo Menu
Buttons Description
1
Tap to open the IMPORT / EXPORT window.
• IMPORT : View the screen of a mobile device or PC connected to the product,
or import data such as images from a connected USB or network drive.
• EXPORT : Share your creations in various ways.
2 Brush Mode Tap to select a mode. You can select from PEN MODE or BRUSH MODE .
3 Palette
Tap to open the Palette. You can select the color and use other options.
•
: Dry colors to stop blending.
• : Extract the color from the selected point.
• : Delete the selected area.
4 Select Select the area you want to capture, send in an email, or print.
5
Undo
Redo
Undo or redo the last action.
• If any page editing actions such as page adding, deleting, and moving are
found, / is reset.
" / can be performed up to 5 times for each individual.
6 Menu Tap to see more options available in the menu.
7 Close the current roll and create a new roll.
" Changes in the thickness depending on the area touching the screen apply immediately. (max. 5.0 cm)
" Brush use is recommended.
" BRUSH MODE supports single touch only.
" The product can distinguish 2048 levels of thickness in BRUSH MODE .
