113
Menu List
Menu item Value (bold text: default value) Explanation
Ratio
1.00: 1, 1.12: 1, 1.25: 1, 1.40: 1,
1.60: 1, 1.80: 1, 2.00: 1,
2 .50: 1 ,
3.20: 1, 4.00: 1, 5.60: 1, 8.00: 1,
16.0: 1, INF: 1
Specifies the degree of compression applied to the audio. The state in which no
compression is applied is defined as “1”.
Attack 0.0– 30 –100msec Specifies the time until compression starts when audio exceeding the threshold is input.
Release 30– 250 –5000msec Adjusts the length of time until compression ends after audio falls below the threshold.
Makeup Gain -40– 0 –40dB Adjusts the final output volume level after applying the compressor.
Equalizer OFF , ON
Turns the equalizer on/off.
Effect
This is a 4-band parametric equalizer. It lets you shape the character of the sound by
boosting or cutting four frequency regions.
Hi Gain -12.0– 0 .0 –12.0dB Boosts or attenuates the high band.
Hi Freq 1.00– 10 .0 –20.0kHz Adjusts the center frequency when changing the tone quality in the high band.
Hi-Mid Gain -12.0– 0 .0 –12.0dB Boosts or attenuates the high-midrange band.
Hi-Mid Freq 20.0Hz– 2 .00kHz –20.0kHz
Adjusts the center frequency when changing the tone quality in the high-midrange
band.
Hi-Mid Q 0.5– 1 .0 –16.0
Adjusts the width of the frequency band when boosting or attenuating high-midrange
band.
Lo-Mid Gain -12.0– 0 .0 –12.0dB Boosts or attenuates the low-midrange band.
Lo-Mid Freq 20.0Hz– 500Hz –20.0kHz Adjusts the center frequency when changing the tone quality in the low-midrange band.
Lo-Mid Q 0.5– 1 .0 –16.0
Adjusts the width of the frequency band when boosting or attenuating low-midrange
band.
Lo Gain -12.0– 0 .0 –12.0dB Boosts or attenuates the low band.
Lo Freq 20.0Hz– 100Hz –2.00kHz Adjusts the center frequency when changing the tone quality in the low band.
(*10) The [4] [6] fader is disabled when “Stereo Link” is “ON”.
(*11) This can be set if “Stereo Link” is “OFF”.
