4
To connect the cable to the Earset:
•
Choose the right cable and connector that
works with your wireless system.
•
Line the cable up to the threaded terminal
on the back of the SE60x and screw the
cable into the Earset. Do not over tighten the
cable.
Connector Cables
The SE60x includes four cables with adapters for some of the most popular wireless microphone
beltpack transmitters.
3.5mm Connector
Works with Sennheiser
®
wireless systems
Hirose
®
4-Pin Connector
Works with most Audio-Technica
®
wireless systems
Switchcraft
®
TA3F Connector
Works with Samson AirLine ATX Series, Concert Series and most AKG
®
wireless systems
Switchcraft
®
TA4F Connector
Works with most Shure
®
wireless systems
