7 EN
STR-AN1000
5-037-028-11(1)
  (power) (page 42)
 Power indicator (page 8)
 SPEAKERS (page 43)
 BLUETOOTH
Switches the receiver to the BLUETOOTH®
function by pressing the button when
[Bluetooth Mode] is set to [Receiver].
When the button is pressed and held for more
than 2 seconds, the receiver enters the pairing
mode.
 DISPLAY MODE
Switches information on the display panel.
 HDMI OUT
 2CH/MULTI, MOVIE, MUSIC (page 47)
 Display panel (page 9)
 360SSM
Activates or deactivates the
360 Spatial Sound Mapping function (page
47).
 ZONE SELECT, ZONE POWER (page
45)
 DIMMER
Adjusts the brightness of the display panel.
Parts and Controls
Receiver
Front panel
 Remote control sensor
Receives signals from remote control.
 PURE DIRECT
The indicator above the button lights up when
the Pure Direct function is activated.
 MASTER VOLUME (page 44)
 INPUT SELECTOR (page 44)
  (USB) port
Connect a USB device here.
 CALIBRATION MIC jack (page 41)
 PHONES jack
Connect headphones here.
