3-3

ASUS PA27DCE OLED Monitor

HDR_PQ Rec2020: Presents ST2084 with Rec.2020 color gamut and

D65 white point.

»

PQ Optimized: Delivers the optimized HDR performance of this

display with as much accuracy as with ST2084 in terms of display

luminance capability.

»

PQ Clip: Preserves PQ curve till displaying maximum luminance with

accuracy. ST2084 code value with higher than display maximum will

be mapped to the maximum luminance.

»

PQ Basic: Presents HDR performance of general HDR supported

displays.

HDR_HLG BT2100: Compliant with BT2100.

HDR_HLG DCI: Compliant with DCI-P3.

User Mode 1/User Mode 2: You can save one or two ProArt Calibration

profiles as User Mode 1/User Mode 2 after executing ProArt Calibration

and then have quick access here.

Please apply the following settings while performing ProArt color calibration:
• Set output dynamic to full range.
• Set output color format to RGB.
• Set output color depth to 8 bit.

Below tables show the default configurations for each ProArt Preset mode:

Function

Standard

sRGB

AdobeRGB

Rec. 709

Color Temp.

6500K

Fixed (6500K)

Fixed (6500K)

6500K

Brightness

50

Fixed 80nits

160nits

100nits

Contrast

80

80

80

80

Sharpness

Enable (0)

Enable (0)

Enable (0)

Enable (0)

Saturation

Middle (50)

Fixed

Middle (50)

Middle (50)

Hue

Middle (50)

Fixed

Middle (50)

Middle (50)

ProArt Palette/

Color

Enable (default)

Fixed

Enable (default)

Enable (default)

Black Level

Enable (default)

Enable (default)

Enable (default)

Enable (default)

Gamma

Enable (2.2)

Fixed (2.2)

Fixed (2.2)

Enable (2.4)

Light Effect

Enable (default)

Fixed

Enable (default)

Enable (default)

Adaptive Color

Enable (default)

Fixed

Fixed

Enable (default)

Uniform Brightness

Enable

(default: Off)

Fixed (On)

Enable

(default: On)

Enable

(default: On)
