Chapter 2� Adjusting and Using your monitor 2-7
Selecting a supported display mode
The display mode of the monitor uses is controlled by the computer� Therefore, refer to your
computer documentation on how to change display modes�
The image size, position and shape might be changed when the display mode changes� This is
normal and the image can be re-adjusted using automatic image setup and the image controls�
Unlike CRT monitors, which require a high refresh rate to minimize flicker, LCD or Flat Panel
technology is inherently flicker-free�
Note: If your system has previously been used with a CRT monitor and is currently configured
to a display mode outside the range of this monitor, you may need to reattach the CRT monitor
temporarily until you have re-configured the system; preferably to 2560 x 1080 at 90 Hz, which is
a common display mode�
The display modes shown below have been optimized at the factory�
Table 2-2. Factory set display modes
Address ability Refresh rate
720 x 400 70 Hz
640 x 480 60 Hz, 72 Hz, 75 Hz
800 x 600 60 Hz, 72 Hz, 75 Hz
1024 x 768 60 Hz, 70 Hz, 75 Hz
1280 x 1024 60 Hz, 75 Hz
1366 x 768 60 Hz
1440 x 900 60 Hz
1600 x 900 60 Hz
1680 x 1050 60 Hz
1920 x 1080 60 Hz
2560 x 1080 90 Hz
480p 60 Hz
576p 50 Hz
720p 50 Hz, 60 Hz
1080p 50 Hz, 60 Hz
2560 x 1080P 90 Hz
