LG 24BK750Y-B 24" 16:9 IPS Monitor - Manual (Page 27)

26
ENG
ENGLISH
SPECIFICATIONS
27BK750Y
LCD Screen Type TFT (Thin Film Transistor) LCD (Liquid Crystal Display)
Panel,Anti-Glare coating
Pixel Pitch 0.3114 mm x 0.3114 mm
Resolution Maximum Resolution 1920 x 1080 @ 60 Hz
Recommended Resolution 1920 x 1080 @ 60 Hz
Video Signal Horizontal Frequency HDMI : 30 KHz to 83 KHz
DVI : 30 KHz to 83 KHz
DP : 30 KHz to 83 KHz
Vertical Frequency HDMI : 56 Hz to75 Hz
DP : 56 Hz to 75 Hz
DVI : 56 Hz to 75 Hz
Synchronization Separate Sync.
Input Connector DVI-D IN, HDMI IN, DP(DisplayPort) IN, DP(DisplayPort) OUT, AUDIO IN(PC), H/P,USB
Power consump-
tion
On mode: 20.3 W Typ. ( ENERGY STAR® standard ) *
28 W Typ. ( Outgoing condition ) **
Sleep Mode ≤ 0.5 W ( Outgoing condition )
Off Mode ≤ 0.003 W
Power Input AC 100-240V ~ 50/60Hz 1.5 A
Environmental
Conditions
Operating Temperature
Operating Humidity
0 °C to 40 °C (32 °F to 104 °F)
Less than 80 %
Storage Temperature
Storage Humidity
-20 °C to 60 °C (-4 °F to 140 °F)
Less than 85 %
Dimension Monitor Size (Width x Height x Depth)
With Stand
611.5 mm x 542.9 mm x 276.1 mm
Without Stand 611.5 mm x 367.5 mm x 59.0 mm
Weight (Without
Packaging)
With Stand 7.6 kg
Without Stand 4.9 kg
Product specifications shown above may be changed without prior notice due to upgrade of product functions.
* The power consumption level can be different by operating condition and monitor setting.
* The On mode power consumption is measured with ENERGY STAR ® test standard.
** The On mode power consumption is measured with LGE test standard ( Full White pattern , Maximum
resolution).
