2-Port DVI Splitter 4
What’s in the box?
OVERVIEW
FEATURES
PART NO. Q-TY DESCRIPTION
DVS2P 1 2-Port DVI Splitter
PS5VDC2A 1 5V DC 2 A
User Manual 1
The DVS2P is a 2-port DVI splitter, which can send one DVI video source signal to two connected DVI
monitors for identical displays.
The DVS2P is plug-and-play, meaning it is ready for immediate use upon connection to input-output
devices and a power supply. Simply connect the splitter to a DVI source and two monitors, then power
on the unit: your DVI video will display on both monitors in stunning Full HD (1920x1200 @ 60Hz).
The DVS2P excels at creating dual-screen displays in a variety of settings and applications. Set up a
DVS2P at bench testing facilities, data servers for better visualization of information, help desks for
unified displays, and more!
DVS2P Front Panel
DVS2P Back Panel
• Send a single DVI video source signal to two connected DVI monitors or flat-panel displays
• Uses PanelLink digital technology
• Supports high-resolutions up to WUXGA
(1920x1200 @ 60Hz, 25-165MHz)
• Can be daisy-chained and cascaded
• Compliant with DVI 1.0 sources and monitors
• Simultaneous DVI monitor display
• Plug-and-play; no additional software required
• Compatible with mounting brackets and rack-mounting kits
